Total Power |
64.1KW |
|
Vertical Joining Cooling System |
2KW Air Conditioning |
|
Vertical Joining Finished Core Conveyor Motor |
1.5KW |
|
Stacker Up and Down Motor |
3KW |
|
Stacker Upper Convey Motor |
1.5KW |
|
Stacker Bottom Convey Motor |
1.1KW |
|
Scissor Lift Motor |
3 KW |
|
Core Veneer Adjustment |
Yes |
|
Variable Speed Adjustment |
Yes |
|
Finished Core Counting System |
Yes |
|
Brush for waste veneer |
Yes |
|
Total Power |
64.1KW |
| Core Veneer Thickness | 1.5-3.6 mm |
| Transfer Speed | 0-35m /Minute (adjustable) |
| Transverse Joining Part: L x W x H | 4400 x 2600 x 2500 mm |
| Vertical Joining Part: L x W x H | 5200 x 2300 x 2200 mm |
| Stacker Part: L x W x H | 4000 x 2200 x 2350 mm |
| System Operation | PLC HMI Touch Screen Delta / Teco |
| Transverse Joining | INVT SERVO DRIVE 3 Kw x 2 no = 6 Kw |
| Transverse Joining Edging Knife& Fixed Length Knife | INVT SERVO DRIVE 3 Kw x 2 no = 6 Kw |
| Transverse Joining Glue Groove Heat | 9 Kw |
| Transverse Joining Cooling System | 1 Kw Air Conditioning |
| Vertical Joining Conveyor | SERVO DRIVE 1.5 Kw |
| Vertical Joining Drive | INVT SERVO DRIVE 3 Kw X 3 No = 9 Kw |
| Vertical Joining Fixed Length Knife | Hydraulic System |
| Finger Cutting Knife | Hydraulic System 11 Kw |
| Vertical Joining Front & Middle Drive Transfer Rollers | 8 pcs x 2 sets = 16 pcs |
| Vertical Joining Rear Drive Transfer Rollers | 4 Pieces |
| Vertical Joining Glue Groove Heat | 7 Kw |
| Vertical Joining Cooling System | 2 Kw Air Conditioning |
| Vertical Joining Finished Core Conveyor Motor | 1.5 Kw |
| Stacker Up and Down Motor | 3 Kw |
| Stacker Upper & Bottom Conveyor Motor | 1.5 Kw + 1.1 Kw = 2.6 Kw |
| Scissor Lift Motor | 3 Kw |
| Core Veneer Adjustment | Yes |
| Variable Speed Adjustment | Yes |
| Finished Core Counting System | Yes |
